Transverse Width 1400mmTransformer Wire Winder Automatic Coil Winding Machine
Description of automatic coil winding machine ZPX1400
Automatic coil winding machine ZPX1400 is one kind of big sized winding equipment to wind transformer coil. This kind of automatic coil winding machine, Máquina de bobinado, is mainly used to wind coils with copper or aluminium round or flat wire. The wound coil can be served as transformer coils and other similar products. With the control system based on PLC, the coil winding machine can guarantee high automation and easy operation. With different parameters input via a touch screen, the automatic coil winding machine can be used to wind different specifications of coils. The automatic coil winding machine features slow starting, smooth running and high automation etc.
Main features of automatic coil winding machine ZPX1400
- slow starting
- smooth running
- full function
- high automation
- High torque
- High precision
Technical parameters of automatic coil winding machine ZPX1400
Typical standard specifications of automatic coil winding machine ZPX1400 are shown below, however the machine can also be manufactured as requested.
| Center Height: | 900mm |
| Winding Shaft Size: | 50x50x1700mm |
| Insulation Decoiler Quantity: | 1 pc |
| Winding Power: | 7.5Kw |
| Winding Speed: | 0 ~ 60 Rpm |
| Speed Regulation: | stepless speed regulation |
| Maximum Rectangular Wire Size: | 5x14mm |
| Round Wire Diameter: | Φ0.3 ~ 5.0mm |
| Maximum Wound Coil Height: | 1400mm |
| Maximum Coil Weight: | 1000kg |
| Counting Mode: | 5-digit counting |
| Max. Turns Preset Number: | 9999.9 |
| Counting Range: | 0 ～ 9999.9 |
Fig 1: Automatic coil winding machine ZPX1400's front view
Fig 2: Automatic coil winding machine ZPX1400's insulation decoiler
